BASIC INFORMATION
| Model | SOG-4K-EXP | SOG-6K-EXP |
| Default Battery System Voltage | 24VDC | 48VDC |
INVERTER OUTPUT
| Rated Power | 4000VA / 4000W | 6000VA / 6000W |
| Surge Power | 8000W | 12000W |
| Waveform | Pure sine wave | |
| AC Voltage Regulation (Batt. Mode) | 230VAC ±5% (Setting) | |
| Inverter Efficiency (Peak) | 92% | |
| Transfer Time | 10ms (UPS / VDE4105) / 20ms (APL) / <50ms typical (Parallel) | |
AC INPUT
| Voltage | 230VAC | |
| Selectable Voltage Range | 170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC (VDE) | |
| Frequency Range | 50Hz / 60Hz (Auto sensing) | |
BATTERY
| Normal Voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27.4VDC | 54.8VDC |
| Overcharge Protection | 30VDC | 60VDC |
SOLAR CHARGER & AC CHARGER
| Maximum PV Array Open Circuit Voltage | 500VDC (450V for parallel) | |
| Charging Algorithm | 3-Step (Flooded, AGM / GEL / Lead Battery), 4-Step (Li) | |
| Maximum PV Array Power | 5000W | 6000W |
| PV Array MPPT Voltage Range | 90~430VDC | 120~430VDC |
| Maximum Solar Charge Current | 100A | 120A |
| Maximum AC Charge Current | 80A | 100A |
| Maximum Charge Current | 100A | 120A |
MECHANICAL SPECIFICATIONS
| Machine Dimension (W×H×D) (mm) | 322×486×134 | 309×505×147 |
| Package Dimension (W×H×D) (mm) | 575×229×425 | 603×260×400 |
| N.W (kg) | 9.5 | 12.5 |
| G.W (kg) | 12 | 13.8 |
OTHER
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | 0°C ~ 50°C | |
| Storage Temperature | -15°C ~ 60°C | |
| Communication Interface | USB / WIFI | |
| Warranty | 2 Years | |
CERTIFICATION & STANDARDS
| CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017 + EN IEC62109-1:2010, EN IEC62109-2:2011) CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011) EN IEC62368-1:2018, EN IEC62109-1:2010, EN IEC62109-2:2011 |
