SLH-US Series(5~10kW)

The SLH-US series is a high-density, 48V split-phase hybrid inverter with IP66 protection, 100% unbalanced output, parallel expansion, multi-battery and generator support, smart time-of-use control, and remote WiFi monitoring, delivering safe, reliable, and flexible power for home, commercial, microgrid, and off-grid energy systems.

Category: Tags: , , Brand:

Usage Scenarios：

• 100% unbalanced output, each phase max. output up to 50% rated power
• Max. 6 pcs parallel for on-grid and off-grid operation
• AC couple to retrofifit existing solar system
• Support multiple batteries parallel
• Max. charging/discharging current of 220A
• Support storing energy from diesel generator
• 48V low voltage battery, transformer isolation design
• IP66 water-proof and dust-proof
• “Time of use” function: a maximum of 6 time segments can be set
• Wifi monitoring

Specification:

Model
Model SLH-5KP2-US SLH-6KP2-US SLH-8KP2-US SLH-10KP2-US
Rated power 5000W 6000W 8000W 10000W

BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~60V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 5000W 6000W 8000W 10000W
Maximum charging/discharging current 120A 150A 190A 220A

PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~540V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4

AC INPUT/OUTPUT DATA
Rated AC Input/Output Active Power 5000W 6000W 8000W 10000W
Max. AC Input/Output Apparent Power 5500VA 6600VA 8800VA 11000VA
Rated AC Input/Output Current 20.8A 25A 33.3A 41.6A
Max. AC Input/Output Current 22.9A 27.5A 36.6A 45.8A
Max. Continuous AC Passthrough (grid to load) 31.2A 37.5A 50A 62.5A
Rated Input/Output Voltage/Range 120V/240V:208V
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Split Phase
DC Current Injection <0.5%

EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%

PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection,
DC switch rating for each MPPT, Grid monitoring, Output over current protection,
Gird overvoltage protection-varistor, Integrated all-pole sensitive leakage current,
ISO monitoring, over temperature protection.
Surge Protection AC Type III
Overvoltage Category AC Type III

GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted

MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 816*404*567
N.W(kg) 38
(Excluding Connectors and Brackets)
G.W(kg) 42
Warranty 5 Year
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy

CERTIFICATION & STANDARDS
NBT32004-2013
