Usage Scenarios：
• Multiple operation modes: Grid-tie,off grid with storage backup
• IP66 water-proof and dust-proof
• MPPT voltage range 120-500V
• Support LCD display&Smart LCD setting
• Available Export control CT sensor function
• Multiple communications: RS485,GPRS and wifi etc
• Full protection function:Over-voltage,over-frequency, over-current, over-temperature,and AC short-circuit automatic protection
• Intelligent BMS battery management function
• Fanless low-noise design
• Wifi monitoring
Specification:
Model
| Model |
SLH-5KL1-EU |
SLH-6KL1-EU |
| Rated Power |
5000W |
6000W |
| Nominal Battery System Voltage |
48V |
PV INPUT(DC)
| Maximum Recommended DC Power |
6500W |
7800W |
| Nominal DC operating voltage |
360V |
| Maximum DC Voltage |
500V |
| MPPT voltage range |
120V~500V |
| Maximum input current |
15A / 15A |
| No.of MPP tracker |
2 |
| Strings per MPP tracker |
>1 |
INVERTER INPUT/ OUTPUT(AC)
| Nominal AC input/ output power |
5000W |
6000W |
| Nominal input/ output voltage; range |
220/230/240V;180-280V |
| AC grid frequency; range |
50/60Hz; 45~55/55-65Hz |
| Nominal input/ output current |
21.7A |
26A |
| Maximum input/ output current |
22.7A |
27.2A |
| Inrush current (spike/duration) |
57.5A/5.2us |
| Total harmonic distortion i(THDi) |
<3% |
| Power factor at rated power |
1 |
| Displacement power factor |
0.8leading~0.8lagging |
| Grid type |
Single phase |
BATTERY MODE OUTPUT(AC)
| Output Rated Power |
5000W |
6000W |
| Nominal output voltage; accuracy range |
230±1% |
| Output ferequency; accuracy range |
50/60Hz (optional)±0.2% |
| Output rated current |
21.7A |
26A |
| Output waveform |
Pure sine wave |
| Peak power |
7500W,10s |
9000W,10s |
| Total harmonic distortion v (linear load) |
<3% |
BATTERY & CHARGER
| Battery type |
Lead-acid battery / Lithium battery |
| Battery voltage |
48V |
| Battery voltage range |
40~60V |
| Charging curve |
3-stage adaptive with maintenance |
| Protection |
Over-current protection / Over-temperature protection |
| Maximum charging power |
>5000W |
>6000W |
| Maximum charging currernt |
<100A |
<125A |
EFFICIENCY
| Maximum efficiency |
97.1% |
| Euro-efficiency |
96.5% |
| MPPT efficiency |
99.8% |
PROTECTION DEVICES
GENERAL
| Machine Dimension (W*H*D)(mm) |
420*480*215 |
| Package Dimension (W*H*D)(mm) |
610*327*595 |
| N.W(kg) |
30 |
| G.W(kg) |
32 |
| DC connection |
H4 / MC4 |
| AC connection |
Terminal Block |
| Display |
LED+LCD |
| Communication interfaces |
Wi-Fi / USB / GPRS / RS485 |
| Ingress protection rating |
IP66 |
| Humidity |
0~95% RH(No codensing) |
| Operating temperature range |
-25°C+60°C With derating above 45°C |
| Cooling concept |
Natural |
| Altitude |
<3000m |
GENERAL
CE-EMC+LVD (EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011); CE-LVD(EN62477-1:2022); IEC60529; EN50549-1:2019
Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021); C10/C11; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G98+G99 |
